Mechanical computer-aided design (MCAD) software is primarily used by mechanical engineers and technical designers to create and modify product designs. Also known as mechanical design automation (MDA) software, it enables engineers to produce two-dimensional (2D) and three-dimensional (3D) models with high precision. Generating a virtual 3D representation, it assists users in viewing the object from various angles and testing and simulating it before creating a prototype.

MCAD software is used in various industries, including automotive, construction, electronics, architecture, etc. Simple MCAD software packages help create 2D diagrams of mechanical structures. MCAD software can also be used for generating and modifying complex 3D geometry. The tool helps in simulating designs and documenting manufacturing information.

Product development processes may require mechanical systems to interact with electronic systems. For manufacturing smart electronics, the electronic and mechanical teams need to collaborate to address the complexities of product design and development. While integrated electronic CAD (ECAD) and MCAD solutions are available, it is vital to understand the difference between the two types of software.

Unlike MCAD software, used for designing mechanical structures, ECAD software assists electrical engineers in various stages of electronic product design, from conception to manufacturing. Typically, MCAD software is used for mechanical design; however, it can be used in the electronic design process for designing 3D models of electronic enclosures and equipment. Additionally, it helps in the iteration of designs which involves repeated prototyping, testing, and analyzing a product to refine it.

To qualify for inclusion in the Mechanical Computer-Aided Design (MCAD) category, a product must:

• Assist engineers and technical designers to create and modify 2D drawings or 3D models of mechanical structures
• Allow engineers to simulate the product's behavior under various physical conditions through thermal and structural analysis.
• Generate output files or engineering documentation containing detailed blueprints conveying information on materials, measurements, tolerance levels at high temperatures, and processes and specifications for manufacturing.
• Assist users in creating mechanical assemblies from 3D models of components.
