DipTrace

46 reviews

PCB Layout is a high-level engineering tool for board design featuring smart manual routing of high-speed and differential signals, shape-based autorouter, advanced verification, and wide import/export capabilities. Design requirements are defined by net classes, class-to-class rules, and detailed settings by object types for each class or layer. DipTrace features design process with real-time DRC, which reports errors on the fly before actually making them. The board can be previewed in 3D and exported for mechanical CAD modeling. Design Rule Check with in-depth detailing, Net Connectivity verification, and comparing to source schematic ensure maximum quality of the final product.
