OnsiteBIM

0 reviews

OnsiteBIM transforms jobsite quality assurance, pre-pour verification, and MEP clash detection by putting full 3D BIM models directly into the hands of field teams. Key Capabilities: • 1:1 Life-Size AR Overlay: Walk active jobsites and visually compare planned structural and MEP installations against physical reality before concrete is poured or drywall is hung. • 1-Second Auto-Alignment: Mount a calibrated paper Alignment Target to a column or slab benchmark. The camera detects the target and instantly aligns the 3D model with sub-centimeter mathematical accuracy. • 100% Offline & Private: No mandatory cloud uploads, no account creation required, and zero network latency. Works in shielded basements and tunnels without an internet connection. • Complete BIM Layer Control: Toggle and isolate architectural, structural, and MEP trades with single-touch layer filtering. • Open-Source Workflow: Free Autodesk Revit component family (.RFA) and 1-click IFC export profiles available on GitHub (github.com/onsitebim/bim-alignment-toolkit). • LiDAR Depth Occlusion: On LiDAR-equipped iPhone and iPad Pro devices, physical columns and walls realistically occlude virtual ductwork and conduit.
